BRUSHLESS 36V DC IRREVERSIBLE - with leaf up to 7 m lenght - with mechanical stopper in opening and closing
SMARTY7
Electromechanical actuator BRUSHLESS, low voltage, super intensive use. Irreversible. For swing gates with gate leaf up to 7 m.
Brushless
Intensive use
Digital Encoder
Industrial sector
Commercial sector
| 230V AC - 50Hz | |
| 36V | |
| 200W | |
| Intensive use | |
| 600 - 7000N | |
| -20 C° +55 C° | |
| IP44 | |
| Irreversible | |
| 1,6 cm/s | |
| 35-50 s | |
| 520 mm | |
| Mechanical stopper in opening and closing | |
| 230V: EDGE1/BOX - 115V: EDGE1/BOX/115 | |
| Digital native encoder SENSORLESS 48 PPR | |
| 1000 | |
| 1312 x 116 x 165 | |
| 17,1 | |
| 36 |
Dimensions
Predisposition for standard installation
MC782
Kit 2 mechanical stop SMARTY series.
Kit 2 mechanical stop SMARTY series.
KT238
Kit 3 hinge plates long series, to weld, for series SMARTY7 - SMARTY7R.
Kit 3 hinge plates long series, to weld, for series SMARTY7 - SMARTY7R.
R99/C/001
Signboard "Automatic Opening".
Signboard "Automatic Opening".
RL671
Metallic wire length 3 m for release from outside.
Metallic wire length 3 m for release from outside.
B74/BCONNECT vers. HW2
Module WI-FI B-CONNECT - Remote management and programming system in IP web browser mode via Wi-Fi hot spot P2P connection for Brushless control units (B70/2ML - EDGE1 - CTRL - B70/1DC - B70/1DCHP - B70/1T - B70/1THP - F70/IPU36).
Module WI-FI B-CONNECT - Remote management and programming system in IP web browser mode via Wi-Fi hot spot P2P connection for Brushless control units (B70/2ML - EDGE1 - CTRL - B70/1DC - B70/1DCHP - B70/1T - B70/1THP - F70/IPU36).
R99/C/001AL
Signboard "Automatic Opening" Aluminium version.
Signboard "Automatic Opening" Aluminium version.
B71/PBX36/BOX/115
Hybrid inverter, “Network Assisted” version, for powering the automation. Also provides a battery-charger function thanks to the connection to the solar panels or mains supply for powering the 36V DC brushless digital controllers with a mains voltage of 115V AC.
Hybrid inverter, “Network Assisted” version, for powering the automation. Also provides a battery-charger function thanks to the connection to the solar panels or mains supply for powering the 36V DC brushless digital controllers with a mains voltage of 115V AC.
B71/PBX36/BOX
Hybrid inverter, “Network Assisted” version, for powering the automation. Also provides a battery-charger function thanks to the connection to the solar panels or mains supply for powering the 36V DC brushless digital controllers with a mains voltage of 230V AC.
Hybrid inverter, “Network Assisted” version, for powering the automation. Also provides a battery-charger function thanks to the connection to the solar panels or mains supply for powering the 36V DC brushless digital controllers with a mains voltage of 230V AC.
B71/PBX/BOX
Hybrid inverter, “Full Solar” version, for powering the automation. Also provides a battery-charger function thanks to the connection to the solar panels for powering the brushless digital controllers.
Hybrid inverter, “Full Solar” version, for powering the automation. Also provides a battery-charger function thanks to the connection to the solar panels for powering the brushless digital controllers.
Size in Cm: Lenght: 134 - Widht.: 13 - Heigth: 16
